Shell-Tube Condenser Specification

Features:

The shell-and-tube heat exchanger has a solid structure and can be manufactured with a variety of materials. It has strong adaptability, and is especially widely used in high temperature, high pressure and large devices.

Typical Application

Condenser in Screw chiller system

The closed shell-and-tube condenser in which cooling water flows horizontally through the horizontal tube bundle under pressure is often used in large and medium-sized ammonia or Freon refrigeration units. Placed horizontally, the water flows through it several times. The cooling water has a long stroke, a large flow rate, and a high water-side heat transfer coefficient; the temperature difference between the inlet and outlet water is obviously large under the condition of reducing the amount of cooling water; the structure is compact and takes less space.

GHE provides stable quality shell and tube condensers for customers in HVAC and refrigeration industries.We help customers create value with our honest attitude and competitive prices.

Condenser Specification

1）Single circuit

Note ：

1. 工作条件 / Working Conditions (Cap. A)：Te=2℃, Tc=40℃, Tsuc=5℃, T1=30℃, T2=35℃;

2. 工作条件 / Working Conditions (Cap. B)：Te=2℃, Tc=35℃, Tsuc=5℃, T1=18℃, T2=29℃;

2）Double circuit

 Note ：

1. Working Conditions (Cap. A)：Te=2℃, Tc=40℃, Tsuc=5℃, T1=30℃, T2=35℃;

2. Working Conditions (Cap. B)：Te=2℃, Tc=35℃, Tsuc=5℃, T1=18℃, T2=29℃;

2）Triple circuit

Note ：

1. Working Conditions (Cap. A)：Te=2℃, Tc=40℃, Tsuc=5℃, T1=30℃, T2=35℃;

2. Working Conditions (Cap. B)：Te=2℃, Tc=35℃, Tsuc=5℃, T1=18℃, T2=29℃;
